State Bicycle Co. Core-Line

State Bicycle Co. Core-Line
  • Color: Ghoul
  • Color: Ghoul
  • Color: Ghoul
  • Color: Pigeon
  • Color: Pigeon
  • Color: Pigeon
  • Color: Wulf
  • Color: Wulf
  • Color: Wulf
Color: Wulf
Handlebar: Riser Bar
Size: 46cm
Please select options Unavailable


Our Core-Line fixed gear and single speed bicycles are what we're best known for. Built on a durable steel frame with seatstay rack mounts, eyelet mounts on the fork, and cable stops, the Core Line models are as stylish as they are versatile. Quality components, a flip-flop hub that allows you to ride fixed gear or freewheel, and comfortable grips will keep you riding hassle-free for years to come.

bike frame with labeled dimensions
Bike Sizes:
A. Reach 368mm 374mm 380mm 386mm
B. Stack 508mm 522mm 536mm 570mm
C. Standover 733mm 751mm 775mm 811mm
D. Effective Top Tube 513mm 522mm 538mm 555mm
E. Head Tube Angle 71.5° 72° 71° 73°
F. Head Tube Length 105mm 105mm 105mm 135mm
G. Seat Tube Angle 74° 74° 73° 73°
H. Seat Tube Length 460mm 500mm 540mm 580mm
I. Bottom Bracket Height 268.5mm 268.5mm 268.5mm 268.5mm
J. Bottom Bracket Drop 50mm 50mm 50mm 50mm
K. Fork Rake/Offset 45mm 45mm 45mm 45mm
M. Wheelbase 975mm 985mm 989mm 1003mm
O. Chainstay Length 405mm 405mm 405mm 405mm


Frame Hi Tensile Steel
Fork Hi Tensile Steel, 1 1/8 threadless steerer
Wheels 700c Aluminum Wheel Set, Rim Depth: 40mm
Hubs Sealed Bearing, Flip-Flop Hub, 16T Freewheel and Fixed Cog, Spacing: F: 100mm / R: 120mm, Bolts: F: M10 / R: M10
Spokes 14G Stainless Steel, 3 Cross Pattern
Tires Kenda Brand, 700c x 25, Suggested Max Tire: 28mm
Bottom Bracket Sealed Cartridge, JIS Square Taper, English Threaded, 68mm x 103mm
Crankset Forged 6061 Aluminum, Crank Arm Length: 170mm
Chainrings 44T, 130 BCD
Chain YAB Chain
Brakes Dual Pivot, Forged Alloy, Clamp Diameter: 23.8mm
Handlebars Aluminum, Bullhorn: 420mm, Drop: 450mm, Riser: 570mm
Stem Steel, Clamp Diameter: 25.4mm, Length: 90mm, Rise: +/- 7°
Headset 1 1/8 threadless
Seatpost Alloy, Diameter: 27.2mm, Length: 300mm
Saddle Polyurethane, Steel Rails
Pedals Plastic Platform

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Wulf / Riser Bar / 46cm 796201631890 43-WLF2-046-RIS 210000007806
